Technical data


XR 4.0 Software measure X-ray

Article no: 14414-61
Function and Applications

Software package of the "measure" series for controlling the XR 4.0 expert unit (X-ray unit). XR 4.0 measure X-ray consists of a module for device control and measurement data recording and a module for measurement data processing (main program).

Benefits

Plug & measure

  • Automatic identification of the connected devices of the XR 4.0 series
  • Loading of predefined settings
  • Working directly without the need for specialist knowledge

Double control

  • Simultaneous operation of the XR 4.0 expert Unit via manual control and via a computer
  • No restrictions concerning the execution of experiments

Plug & measure

  • The intuitive user concept considerably simplifies the operation of such a complex device and puts the experiment into the focus of attention.

Multilingual

  • XR 4.0 measure X-ray is available in more than 20 languages, among them German, English, French, Spanish, Arabic and Russian. As a result, XR measure 4.0 software is also suitable for beginners' laboratory courses at universities and the secondary school level.

Reference experiments

  • The comprehensive collection of reference experiments simplifies the selection of suitable experiments and can be used as a template for own experiment scripts/laboratory handbooks.
  • All of the relevant topics concerning the characterisation and application of X-rays are documented.
  • Experiment descriptions in PDF files with learning objectives, brief description, set-up picture, equipment list, experiment procedure, reference results with a reference to the theoretical background, and device and software settings that are specifically adapted to the experiment.
  • All of the experiment-relevant settings can be loaded at the push of a button.
  • The experiment descriptions include configuration files and example measurements. They are provided free of charge on the measure DVD.

System requirements

  • PC with at least a Pentium 3 processor, 512 MB RAM, 1 GB free hard drive space, DVD drive, USB 2.0, Microsoft ®Windows XP or higher.
