The shunt motor (DEMO) with Cobra SMARTsense

Article no: P1433569

<!DOCTYPE html PUBLIC "-//W3C//DTD XHTML 1.0 Transitional//EN" "http://www.w3.org/TR/xhtml1/DTD/xhtml1-transitional.dtd"> Unknown

Principle

An electromotor can also be operated with an electromagnet as a field magnet. If armature coils are connected parallel to the field coils, then this is called a shunt-wound motor. The properties of this motor are studied by observing the direction of rotation and measuring the electric current.

Benefits

Particularly comprehensible and didactically prepared description of experiments (reference to everyday life, etc.) incl. protocol questions
Future-oriented teaching: Integration into digital science lessons
Increased motivation among students through use of the intuitive measureAPP
Increased media literacy
Demonstrative experiment due to large instruments
Easy and sturdy setup

Scope of delivery

Bench clamp	02012-00	1
Plate holder, opening width 2 - 35 mm	06509-00	1
Iron core, U-shaped, laminated	06501-00	1
Coil, 1200 turns	06515-01	2
Motor set	06550-00	1
Rotor coil, Double-T armature	06554-00	1
Cord pulley	06558-01	1
Connecting cable, 32 A, red, various lengths	07362-01	3
Connecting cable, 32 A, blue, various lengths	07362-04	3
measureAPP - the free measurement software for all devices and operating systems	14581-61	1
PHYWE Power supply, universal, analog display DC: 18 V, 5 A / AC: 15 V, 5 A	13503-93	1
