Function and Application
The Cobra SMARTsense Code is a programmable output device (actuator) that combines with all Cobra SMARTsense sensors. In the free measureAPP, pupils program 2 relays, LEDs, speaker and display visually via Blockly integration or via the trigger function – no programming experience required. From simple switching logic to complex automation: the output elements respond directly to sensor values, making programming concepts tangible and hands-on.
Cobra SMARTsense Code has a variety of output elements such as 2 relays, LEDs, speakers and a color display. These output elements can be perfectly combined with other SMARTsense sensors and thus offer an easy way to learn the basics of automation and home automation.
Benefits
- Blockly integration – Program the actuator visually by drag-and-drop directly in the measureAPP – no programming knowledge required.
- Simplicity – Get started straight away with any Bluetooth-enabled device and the free measureAPP.
- Real-time feedback – Output elements respond immediately to sensor values, cause and effect directly visible.
- Versatile output elements – Relays, RGB LED, speaker and colour display in one device.
- Real-world applications – The 2 relays allow real electrical loads to be switched.
- Maximum compatibility – Works with all Cobra SMARTsense sensors.
Equipment and Technical Data
- 2x Relais:
- Max. Switching power DC: 30V / 10A
- Max. Switching power AC: 250V / 10A
- RGB LED
- OLED-Display:
- Size: 1,44 "
- Resolution: 128x128 Pixel
- Colors: 65.000
- Loudspeaker:
- Frequency Range: 10 Hz ... 10000 Hz
- 5x Input Buttons
- Bluetooth version: 5.4
The sensor contains a USB-C rechargeable lithium polymer battery.
